Description
Electrical Specifications - Three Phase 120/240 Volt or 120/208 Volt
- Power Rating - Continuous Watts - 120/240 Volt
- 145,000
- A.C. Output Voltage
- 120/240
- Phase, Frequency
- 3-Phase, 60 hz
- Amps (continuous)
- 436 Per Phase
- Motor Starting
- 70 HP
- Generator Speed
- 1800 RPM
- Power Rating - Continuous Watts - 120/208 Volt
- 145,000
- A.C. Output Voltage
- 120/208
- Phase, Frequency
- 3-Phase, 60 hz
- Amps (continuous)
- 503 Per Phase
- Motor Starting
- 70 HP
- Generator Speed
- 1800 RPM
Power Input Panel
- Tractor HP Required
- 290
- PTO Input Speed
- 1000 RPM
- Input Shaft
- 1 3/4" 20-spline
Power Output Panel
- 120 Volt Outlet
- (1) 20 Amp Nema 5-20R Duplex
- 240 Volt Outlet
- (1) 50 Amp Nema 6-50R
- Main Breaker
- 350 Amp
Size & Weight
- Dimensions
- L 47 x W 27 x H 30.4
- Net Weight
- 1494 Lbs
- Shipping Dimensions
- L 55.25 x W 28.5 x H 36
- Shipping Weight
- 1504 Lbs
Warranty - 3 Years
