Winco DP5000/T Portable Generator

$1,530.00

The The DP5000 professional portable generator has been redesigned to include our YourGen hour meter. This unit is just as dependable and durable as our Big Dog units, engineered for residential and professional applications.

Printable Brochures:

DP5000/T



Dolly Kit

2-Wheel Dolly Kit

Generator Cover

Canvas Generator Cover

Line Voltage Monitor

Line Voltage Monitor

30 Amp Plug

30 Amp Plug

Maintenance Kit

Maintenance Kit

Battery

Battery

Compare

Description

FEATURES

  • Honda GX270 Engine - You expect the best, you get the best.  The Honda GX270 engine has more power, lower fuel consumption, and lower emissions than previous versions.
  • Low Oil Protection - In the event there is a low oil level, the engine will shut down to protect the engine from damage.
  • 8 Gallon Fuel Tank - The EPA-approval steel fuel tank design eliminates carbon emissions.
  • 100% Load Tested - Every generator is fully tested prior to leaving Winco's facility.

DP5000/T Engine Specifications

ENGINE BRANDHONDA
ENGINE MODELGX270
ENGINE STARTERRECOIL
ENGINE SPEED3600 RPM
ENGINE CYLINDERSSINGLE
DISPLACEMENT/TYPE270 CC / OHV
FREQUENCY REGULATION+/- 3%
LOW OIL PROTECTIONSTANDARD
RECOMMENDED OIL10W-30
OIL CAPACITY1.2 QT
FUEL TANK8 GAL
FUEL GAGEON TANK
FULL LOAD RUN TIME10.6 HOURS
FUEL CONSUMPTIONGAL/HR
100%0.75
75%0.59
50%0.44
25%0.33
0%0.23
DERATES ABOVE SEA LEVEL EVERY 1,000 FT3.5%

DP5000/T Generator Specifications

STARTING WATTS5,000
RUNNING WATTS4,560
RUNNING AMPS @120 VAC38
RUNNING AMPS @240 VAC19
VOLTAGE REGULATIONCAPACITOR +/- 5%
MAIN CIRCUIT BREAKER20 AMP, 240V (GFCI)
BONDED NEUTRALYES
120 VOLT RECEPTACLES(2) NEMA 5-20 20A (GFCI)
120/240 VOLT RECEPTACLES(1) NEMA L14-30 30A (GFCI)
YOURGEN METERSTANDARD
MOTOR STARTING (CODE G)1.5 HP
DBA @ 7 METERS80.6
TOTAL HARMONIC DISTORTION<6%
LIFTING EYESTANDARD
2 WHEEL DOLLY KITOPTIONAL
INSULATIONCLASS H
PROTECTIVE ROLL FRAME1.25" DIAMETER 14 GAUGE STEEL
ASSEMBLED INUSA
EPA APPROVEDYES
CARB APPROVEDYES
CSA APPROVEDNO
UNIT WARRANTY3 YEARS COMMERCIAL
SHIPPING DIMENSIONS30" x 22" x 24"
SHIPPING WEIGHT178 LBS
FREIGHT CLASS70

Additional information

Weight 178 lbs
Dimensions 30 × 22 × 24 in
Freight

FREE Freight to a Business Address – The customer is responsible for unloading merchandise upon delivery.
